Our TS family of impellers is thought for applications that require the highest rotation speed, and are particularly suitable for compressors and radiators.
230 - 906 mm
25°-50° T -40° C to +140° C° TS impellers are manufactured assembling airfoil profile blades with a light aluminum alloy hub. The impellers are thought to be employed in applications that require the highest rotation speeds. The impellers are available in configurations with 6/8/10/14/20 blades both for clockwise and anticlockwise rotation. TS blades are available in two models: G, and D, with right or left fixed setting angles ranging from 25° to 50°. TS impellers can produce a sucking or blowing air flow.
TS impellers are manufactured assembling airfoil profile blades with a light aluminum alloy hub. The impellers are available in configurations with 6/8/10/14/20 blades both for clockwise and anticlockwise rotation. TS blades are available in two models: G, and D, with right or left fixed setting angles ranging from 25° to 50°. TS impellers can produce a sucking or blowing air flow.
| Material | Description | Color | Op. temperature |
|---|---|---|---|
| PAT | PA66 polyamide for railway applications | From -40° to +120°C | |
| PVDF | Foraflon (FDA certified) | From -40°C to +120°C | |
| PP | Polypropylene (PP) | From -10°C to +85°C | |
| PPG | Glass Reinforced Polypropylene (PP 30% glass) | From -20°C to +85°C | |
| PAG | Glass Reinforced Polyamide (PA6) | From -40°C to +120°C | |
| RYT | Ryton | From -50°C to +200°C | |
| PAA (ATEX) | Antistatic Polyamide | From -40°C to +120°C | |
| PAX (ATEX) | Antistatic, Self extinguishing PA | From -40°C to +120°C | |
| PAM (ATEX) | Antistatic, Self extinguishing, Magnetically shielded PA | From -40°C to +120°C |
315-630 mm T -40° C to +120° C°
